Aluminium circle open-book blanking production line main equipment have : feeding trolley, uncoiler, leveling machine, feeder, swing unit, special closed single point of mechanical press and quick die change equipment, pallet unit, scrap shear, hydraulic system, electrical control system, etc.



Production line technical features:



1, CNC automatic, should have the production line since coil open-book, until the whole roll material blanking completed without human contact among any quantity, do not need any adjustment, fundamentally eliminate the ordinary punch punch production safety and product quality hidden trouble.



2, the line can use direct wafer production volumes, don't need to do a coil slitting and cut processing, reduced the production process, reduce the cost of production, reduce the damage on the surface of the coil may, produce wafer to ensure that no oil, no scratches.



3, this line make full use of the width of the coil, with high precision servo motor drive systems and control, make the wafer spacing and wafer to minimize the edge of the distance, radically reduce the amount of waste, the utilization rate of raw materials more than 80%.



4, production speed can reach 40 to 55 pieces per minute, improved the production efficiency.



5, due to the modular mould design, when converting wafer production specifications, conversion time can be reduced to 15 minutes.It can produce wafer range from 85 mm to 85 mm in diameter.



6, advanced an open-book leveling machine system, the six heavy type, high rigid mechanical press, automatic palletizing system, etc., to ensure the wafer product of high quality.
